In order to store a greater number of pallets, double-deep racks can be installed enabling one pallet to be placed in front of another on each side of the aisle.
Aisle configurations are in 3 main categories:
- Standard Aisle(Propane Sit Down Fork Trucks) 11ft to 14ft Aisles
- Narrow Aisle(Reach Trucks) 8ft to 9.5ft Aisles
- Very Narrow Aisle(Turret Truck, Swing Reach Truck, Drexels, Bendi, Order Pickers) 54″ to 72″ Aisles
NOTE: There are MANY things to consider when designing Selective Pallet Rack Systems. Please call us for help. Selective Pallet Racking systems can be designed in an infinite number of configurations and sizes.
CLICK ON IMAGE TO ENLARGE
PRODUCT MATRIX
Upright Frame Dimensions:
Height = 8ft, 10ft, 12ft, 14ft, 16ft, 18ft, 20ft, 22ft, 24ft, 26ft, 28ft, 30ft
These are the normal sizes but, we can make any size up to 40ft tall
Depth = 36″, 42″, 48″
These are the standard depths but we can make any depth needed
Other less common depths are 30″, 44″, 60″
We can fabricate any length for your application
Beam Dimensions:
Beams = 4ft, 8ft, 9ft, 10ft, 12ft
These are the standard most common sizes
Other less common sizes are 5ft, 6ft, 92″, 94″
We can fabricate any length for your application
Note:
Capacities of each of these upright frames and beams vary.
It depends on the pallet weights and seismic zones.
CALL US or INQUIRE to get correct pallet racking for your application.
Very Quick back of the napkin math on selective pallet rack would be $50 per pallet position including the ground. If you choose to have some type of support structure under the pallets like wire decking or front to back supports you will want to budget $65-$70 per pallet position including the ground position. This is an all in budget (material, labor, freight). Hope this helps! Call us to help you quickly design a solution for your warehouse!
